Automatic/Manual Metallographic Cutting Machine/ Metallographic Table/Wheel Manual Abrasive Saw Cutting Machine
Product Description
Beta- 300 series, has integrated a variety of different cutting methods and techniques, can obtain superior cut surface even for a heavy duty cutting applications. Its automatic cutting guarantees the highest level of reproducibility of the specimen.
Specifications
| Items | Beta-300 Pro | Beta-300 MY | Beta-300 M |
| Safety | Emergency-Stop | Brake on cut-off wheel and table-feed | Brake on cut-off wheel |
| Door-open |
| Current overload | Automatic adjustment | Trip protection |
| Joystick misoperation | Two hand control | -- | -- |
| Max. Wheel Diameter | Φ300mm | Φ300mm | Φ300mm |
| Min. Wheel Diameter | Φ200mm | Φ200mm | Φ200mm |
| Max. Cutting capacity. Φ | Φ110mm | Φ110mm | Φ110mm |
| Max. Cutting Capacity. HxD | 80x200mm | 80x200 | 80x200 |
| Z-Axis Travel ,mm | 150 | 150 | 150 |
| Y-Axis Travel,mm | 220 | 220 | 220 |
| X-Axis Travel,mm | 100 | - | - |
| T-table Dimensions,mm | 280x536(636) | 280x636 | 280x636 |
| T-Slot Dimension,mm | 12 | 12 | 12 |
| Cutting motor power | 4 | 4 | 4 |
| Power Input | AC 220V/380V, 50/60Hz,3 phase,4 Kw |
| Wheel Speed,RPM | 1000-3500 | 2800 | 2800 |
| Control Panel | 7 inch Touch Screen | 7 inch Touch Screen | Buttons |
| Items | Beta-300 Pro | Beta-300 MY | Beta-300 M |
| Cutting | Smart Cutting | Auto | Auto | Manual |
| Chop Cutting,Z-Axis | Auto | Manual | Manual |
| Table Feed Cutting,Y-Axis | Auto | Auto | Manual |
| Pulse Cutting | Y-Axis | Y-Axis | - |
| Step Cutting | Yes | - | - |
| Cutting Feed rate,mm/s | 0.02-3 | 0.02-3 | - |
| Laser Alignment | Yes | Option | Option |
| Weight,Kg | 250 | 238 | 225 |
| Size WxDxH,cm(Open) | 92x100x70(117) | 92x100x70(117) | 92x100x70(117) |
| Recirculation coolant, Liter | 80 | 80 | 80 |
Product Features
1. Programmable with HMI touch screen controls and pre-set 20 optimized cutting parameters.
2. X-Y-Z axes cutting capability and joystick position control.
3. Multiple cutting modes to meet the variety of requirements for different samples.
4. Intelligent feed rate adjustment according to a preset cutting force.
5. Push up - sliding door design, with bigger workspace and table, easy to clamp and handling.
6. Robust and reliable with low noise and emission levels.
